Illustration similarly

• Interface to generate key strokes
• Up to 16 keys connectable
• Every key is able to generate diffent key strokes at closing and releasing the key
• Black plastic housing 45 x 90 x 23 mm (IP30)
• configuration software for key assignment
• No driver installation needed for code programming with Windows® variants that support USB. (®Microsoft Windows is a registered trademark of the Microsoft Corporation.)
• RoHS, CE & EN60950 conform/ IP30
• indoor use only
• any device identifies with a unique serial number
• power input 30 mA
• 4 years warranty
• Made in Germany

Description

The device USB-Key16 offers the possibility of connecting up to 16 different keys which will send individually keyboard codes. The USB- Key16 register as a keyboard when connecting to the PC. When a channel is switched it will send a preprogrammed key code to the As a unique feature this device offers the option to send another key code when the key is released.

The following options are available, programmable per key:

1. Send key code when the chsnnel is closed
2. like 1. but send another key code when the channel is released
3. like 1. but the key code is repeated as long as the channel is closed

The USB-Key16 is 40x90x23mm in size. The USB-Key16 is for indoor use only and should be protected against humidity. The permissible operating temperature range is 10° - 60° Celsius. The device is equipped with a 1.9 m USB cable.

The equipment shares the interface with the USB-IO16.

The switches can be connected directly with the USB-Key16, e.g. the first switch with pin 1 and pin 14. A resistor is not necessary.

The usage of the USB-Key16 is strictly prohibited, if the failure of the device will harm people. The usage in medical applications of any kind request the written permission of the Cleware GmbH.

The USB-Key16 comes with software to assign the contacts to key functions.

The product USB-Key16 comes with software available via Internet free of charge. New versions are made available in the Cleware download area and may be downloaded free.

A connection set, consisting of two 25-pol D-Sub-sockets, per one with soldering connections and one with flat cable connection, a suitable cap as well as approx.. 1 m 25-pin colored flat cable, also available here.



Complete solution

A solution integrated in a graceful designed foot switch offers the f-pro-series, which is made in co-operation with dr. dresing & pehl GmbH.

More informations about this Foot-Switch available at www.f-pro.deor www.audiotranskription.de.
